Specifications of PCB Jack Series
Temperature
-40-70 oC
Withstand Voltage
AC1000V(50Hz)/min
Rated load
AC 125V1.5A
Actuating Force
5-15N
Contact Resistance
<0.03Ω
Life
750cycles
Insulation Resistance
>100MΩ
