Specifications of VGA Connector Series
Temperature
-25-70 oC
Withstand Voltage
AC1000V(50Hz)/min
Rated load
DC 50V 5A
Actuating Force
10-30N
Contact Resistance
<0.03Ω
Life
5000cycles
Insulation Resistance
>100MΩ
