NO.:WP2-5 Name:WP2-5
MORE:
Specifications of WP Push Telminal Board Series
Temperature
-40-55 oC
Withstand Voltage
AC250V(50Hz)/min
Rated load
AC 50V 3A
Keep Wire Foce
1Kgf
Contact Resistance
<0.03Ω
Wire Range
AWG #24-#16
Insulation Resistance
>100MΩ
Life
5000cycles
