Specifications of Lever/Multi Function/Tact Switch Series

Temperature

-10 60 ^oC

Withstand Voltage

AC250V(50Hz)1min

Rated load

Actuating Force

100-300gf

Contact Resistance

Life

>100000cycles

Insulation Resistance

>100MΩ

Remark:1.The Length(L)can be set at the full discretion of the consumer.2.the head can be shaped either round(like O)or square(like 口)
